Built for Aerialist Flight
Price: Call for Pricing
The eZ-AF and eZ-AFXL are complete single-axis run-to-limit joystick hoist kits. They do not require, nor work with, the Raynok automation, drives or other products listed on the eZ-Hoist website.
- Designed for aerialists
- 5HP variable frequency drive (3,7kW for metric speakers)
- Optional shipping pallet and frame to ship hoist and store ballast
- Simple joystick operation with minimal training required
- Comes with joystick pendant and 100’ of pendant cable
- Complies with ANSI E1.43 – 2016
- True plug and play self-contained hoist
- Drum holds 100’ (30,5m) of wire rope or 2 lines at 45’ (15,2m)
- Built-in local control with key bypassable limits
| Standard | Optional | |
|---|---|---|
| Voltage | 200-240vac 3 Phase | 200-240vac 3 Phase |
| HP Rating | 5HP (3,7kW) | 7.5HP (5,5kW) |
| Load Capacity | 350 lbs (159 kg) | 700 lbs (317 kg) |
| Speed | 6 ft/s (1,83m/s) | 4 ft/s (1,2m/s) |
| Brake Resistor | 240w 30Ω | 310w 20Ω |
| Power Input Plug | L15-30 | CS8365 (50A, 250V) |
| Cooling Fans | — | One Thermostat Controlled 120mm |
| Shipping and Ballast Frame | 36” x 35” x 13” tall (91,4 x 88,9 x 33,0cm) | 36” x 36” x 13” (91,4 x 91,4 x 33,0cm) |
| Weight | 419 lbs (190 kg) | 545 lbs (248 kg) |
